LS-A61

Technical parameter

Access by TTLOCK(WiFi) APP Access, M1 Card, Fingerprint, Pass code, Mechanical Key Unlock

TT lock WiFi/BLE App version are available to choose. Convenient APP management system, you can manage your smart lock anytime and anywhere;

Unique stylish thin panel, it can be ﬁt most of the wooden, sliding doors.

One-Touch-Access Biometric Fingerprint sensor on the reader.

Strong and secure Aluminum alloy lock panel, Anti-corrosion and study.

Multi-level administrator settings to help you better manage your smart buildings;

Reversible free style handle.

Emergency power supply in case of lost power;

We can customize production according to your requirements,OEM/ODM;

Support phone system	Android 4.3/IOS7.0 or above		Bluetooth standard	Bluetooth 4.1
Power supply	8*AA alkaline battery		Card type	Mifare M1
Low-voltage alarm	4.8V		Cards Capacity	200pcs
Static current	65 μА		Unlocking way	APP、Password、fingerprint、IC card、key
Working current	<200 μA		Motor output voltage	-0.3V
Unlocking time	P61.5seconds		Fingerprint module	semi-conductor fingerprint module
Working temperature	-20°C~70°C		Fingerprint capacity	120pcs
Key type	Touch screan key		False recognition rate	<0.001%
Password	Customized password+permanent password	150pcs	Rejection rate	<1.0%
Capacity	Dynamic password	No limited

Minimum Order Quantity:	1
Certificate:	ISO, BHMA, SIRIM, CE, FCC, SASO, SONCAP
Delivery Time:	Within 7days
Payment Terms:	100%TT
